Grinding Rod Mill

Grinding Rod Mill

Feeding granularity: ≤25-≤50mm

Production capacity: 0.62-180t/h

Applicable range: This machine can be widely applied in some fields such as refractory, chemical industry, metallurgy, glass and some other industries that have the higher requirement on the uniformity of the finished product.


Product Introduction Parameter Get Latest Price

The rod mill is widely used in metal and nonmetal mines, water conservancy, glass, building materials sector to grind all kinds of ores, rocks and artificial sand. The rod grinding machine can be divided into two kinds: dry and wet. The users can select appropriate type according to their actual situation. As for the processing of quartz sand, dolomite, monazite and other products, the rod grinding mill can be equipped with magnetic separator to conduct iron removal.

Grinding Rod Mill

The wet type rod mill occupies a great position in the rod grinder and it can rival with dry rod mill, but it also have some differences with overflow rod mill. There are also some steel bars to support in the cylinder, which occupies a great position for its development. In addition, its discharge port is relatively large and the structural design is precise and reasonable. It is mainly used in mining, chemical, construction and other industries.

Through the supporting of the steel bars in the cylinder, driven by the motor, the hobbing of wet type rod mill rotates. And then the grinding media is raised to a certain height by centrifugal force and friction and falls down. Putting the materials to be grinded from the outside into the rod grinding machine and the ore grinding media in the cylinder is discharged with the aid of these forces.

Grinding Rod MillGrinding Rod Mill


1. Saving power and energy-saving. Compared with the old type of equipment, it can save more than 40% of the power.

2. Uniform granularity and high output. The usage of advanced controllable feeding and discharging technology and suitable grinding body based on the grinding material makes higher efficienccy.

3. Large impact force and grinding capacity.

4. The fineness of the materials is adjustable. The simple adjustment can change the granularity of the materials: the built-fineness controlls the device and the screening device for the discharging, which make sure that the over-grinded or unqualified products will not mix the finished products.

Technical Data

Shell Specifications (mm)
Shell rotation speed
Feeding size
Discharging size
Processing capacity
Total weight
Diameter Length
MBS0918 900 1800 36-38 ≤25 0.833-0.147 0.62-3.2 18.5 5.9
MBS0924 900 2400 36 ≤25 0.833-0.147 0.81-4.3 22 6.7
MBS1224 1200 2400 36 ≤25 0.833-0.147 1.1-4.9 30 13.9
MBS1530 1500 3000 29.7 ≤25 0.833-0.147 2.4-7.5 75 19.8
MBS1830 1830 3000 25.4 ≤25 0.833-0.147 4.8-11.6 130 34.9
MBS2130 2100 3000 23.7 ≤25 0.833-0.147 14-35 155 46.5
MBS2136 2100 3600 23.7 ≤25 0.833-0.147 19-43 180 48.7
MBS2430 2400 3000 21 ≤50 0.833-0.147 25-65 245 59.7
MBS2736 2700 3600 20.7 ≤50 0.833-0.147 32-86 380 92.5
MBS2740 2700 4000 20.7 ≤50 0.833-0.147 32-92 400 95
MBS3245 3200 4500 18 ≤50 0.833-0.147 64-180 630 149
