Magnetic Separator

Magnetic Separator

Type: Metal ore beneficiaiton equipment

Production capacity: 10-280t/h

Processed Materials: Magnetic separator is one kind of efficient equipment for processing fine feebly magnetic minerals, such as hematite, limonite, wolfram, ilmenite, and tantalum-niobium, etc.

Send e-mail:sales@hxjq.com

Product Introduction Parameter Get Latest Price

Magnetic separators are designed to recover ferromagnetic materials. The separators are available in designs and sizes to provide solutions for all applications. The heart of each separator is the magnetic system with its unique design, which has a proven record of high efficiency.

Magnetic drum separators provide an efficient means for extracting ferrous material from dry, bulk products in free-flowing processing systems. They consist of a stationary permanent magnet, either standard ferrite magnets or high rower rare earth magnets enclosed in a non-magnetic stainless-steel drum. Product flow is diverted so that it falls onto the top and flows across the surface of the drum. Ferrous matter contained in the product flow is drawn to the drum's surface (and held against it) by the powerful magnet housed inside.

Magnetic Separator

Advantages of Magnetic Separator

1. It can improve mineral grade, reduce process under load.

2. It is able to sort the fine ore and return the inferior for re-burning.

3. It will remove impurities, thus improving the quality.

4. It is applicable in a wide range of industries.

Magnetic Separator

As a famous and professional manufacturer of whole sets of mining machinery in China, as for magnetic separator, we produce wet magnetic separator, magnetic drum separator and other types. All of our products are popularized and welcomed at home and abroad.

Technical Data

Model Shell diameter
(mm)
Shell lenght
(mm)
Shell rotation
speed(r/min)
Feeding size
(mm)
Processing capacoty
(t/h)
Power(kw)
CTB6012 600 1200 <35 2-0 10-20 1.5
CTB6018 600 1800 <35 2-0 15-30 2.2
CTB7518 750 1800 <35 2-0 20-45 2.2
CTB9018 900 1800 <35 3-0 40-60 3
CTB9021 900 2100 <35 3-0 45-60 3
CTB9024 900 2400 <28 3-0 45-70 4
CTB1018 1050 1800 <20 3-0 50-75 5.5
CTB1021 1050 2100 <20 3-0 50-100 5.5
CTB1024 1050 2400 <20 3-0 60-120 5.5
CTB1218 1200 1800 <18 3-0 80-140 5.5
CTB1224 1200 2400 <18 3-0 85-180 7.5
CTB1230 1200 3000 <18 3-0 100-180 7.5
CTB1530 1500 3000 <14 3-0 170-280 11

Quick Way to Get Price

Please tell us your materials, capacity and finished product design, we can offer better service for you. Contact Email: sales@hxjq.com
